STEEL: PLAIN
12 Gauge (.105″ 1.0 mm) ASTM 1011 SS GR 33,
14 Gauge (.076) ASTM 1011 SS GR 33
STEEL: PRE-GALVANIZED
12 Gauge (.105″ 1.0 mm) ASTM A653 GR 33,
14 Gauge (.076) ASTM A653 GR 33
Available in
Pre-Galvanized (PG)
Standard lengths are 10′ and 12′
When ordering, add the length or size and finish to the
part number.
Imperial dimensions are illustrated in inches. Metric
dimensions are shown in parenthesis or as noted.
Unless noted, all metric dimensions are in millimeters
and rounded to one decimal place.
